Item \ Model

ALL-11P

ALL-GANG-08

ALL-11C

ALL-11V

Operating System 24324o1419y

Win 3.1 / 95

Win 3.1 / 95

Win 3.1 / 95

Win3.1/ 95

Optional Pack

GANG-08

ALL-11P

NONE

Can be sent to factory for upgrade to ALL-11C

Optional Adapters, Converters & Heads

Over 500 pcs of adapters & converters to support programming devices with 8-300 + pins in all package types

Currently 50 kinds of heads available

* More coming soon *

Over 500 pcs of adapters & converters to support programming devices with 8-300 + pins in all package types

Only supports CNV-xxx converters to support different package types

RAM

*RAM size does not limit the devices, which can be programmed. Upgrading the RAM size can reduce programming times of 2Mbit and larger density memory IC on the GANG-08.

1M bit standard, expandable by adding PCMICA SRAM card.

1M bit standard, expandable by adding PCMICA SRAM card.

1M bit standard

1M bit standard

IC supported

Over 4500 ICs

Over 1500 ICs

Same as ALL-11P

Over 2500 ICs including EPROM,FLASH,GAL and MPU/ Microcontrollers

Power Supply

Built-in heavy duty power supply which can be used for more demanding ALL-LAB instrument options and for heavy production programming.

Same as ALL-11P

Wall plug in power supply suitable for single socket development and production programming.

Same as ALL-11C

Dimension

245mm x 220mm x 50mm

Same as ALL-11P

200mm x 160mm x 50mm

Same as ALL-11C

Weight

3 Kg

3.5 Kg

1.8 Kg

Same as ALL-11C

CE Approval

Approved by TUV to meet CE requirements

Approved by TUV to meet CE requirements

Approved by TUV to meet CE requirements

Approved by TUV to meet CE requirements
