9400 AWY R.2.0

software




9400 AWY R.2.0

Short-haul low/medium capacity

Digital microwave radio links

Versions V2.0.0 to V2.0.4

Test Result Sheet

Site Acceptance Test protocol


This document must be used according to the instructions given in the:

Chapter Line-Up and Commissioning

of the

9400AWY Rel.2.0 V2.0.0-V2.0.3 User Manual P/N 3DB06687HAAA

and

9400AWY Rel.2.0 V2.0.4 User Manual P/N 3DB06687FAAA

ED

DATE (yymmdd)

CHANGE NOTE-ECO

APPRAISAL AUTHORITY

ORIGINATOR

V.Fossati

E.Corradini

V.Fossati

E.Corradini

P.Garofoli

E.Corradini

Threshold tables

Please refer to the 9400AWY User Manuals specified on front page to retrieve updated information you may need, in particular:

Chapter TECHNICAL SPECIFICATIONS, for all technical characteristics like:

Transmitted Power at antenna port (ETSI & ANSI)

ETSI System Characteristics and BER intrusive thresholds

ANSI System Characteristics and BER intrusive thresholds

Chapter ODU PROVISIONING, CHARACTERISTICS AND DESCRIPTION, for detailed information regarding ODU Part Numbers and related frequency shifters and frequency bands.

To easily find such information, or any other information you may need (and that is not included in this handbook), please refer to the document Documentation Quick Guide accessible from the CD-ROM MAIN MENU.

STATION

. . . . . . . . . . . . . . . . . . .

Direction

. . . . . . . . . . . . . . . .

Configuration

. . . . . . . . . . . . . . . . . . . . . .

Date

. . . . / . . . / . . . .

BLANK

TEST RESULT

TOC \o "1-3" \t "h:1;1;h:2;2;h:3;3;H:4;4;H:5;5" Threshold tables PAGEREF _Toc153767684 \h 2 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380034000000

System installation and cabling visual inspection PAGEREF _Toc153767685 \h 6 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380035000000

INDOOR System installation and cabling visual inspection PAGEREF _Toc153767686 \h 6 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380036000000

OUTOOR System installation and cabling visual inspection PAGEREF _Toc153767687 \h 7 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380037000000

Radio Configuration SUMMARY PAGEREF _Toc153767688 \h 8 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380038000000

Radio Power setting and measurement PAGEREF _Toc153767689 \h 9 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380039000000

Radio functionnality test PAGEREF _Toc153767690 \h 10 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600390030000000

NETWORK Element configuration PAGEREF _Toc153767691 \h 11 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600390031000000

NETWORK Element Integration test PAGEREF _Toc153767692 \h 12 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600390032000000

HOP stability test PAGEREF _Toc153767693 \h 13 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600390033000000

SITE ACCEPTANCE TEST PROTOCOL PAGEREF _Toc153767694 \h 15 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600390034000000

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . .

System installation and cabling visual inspection

INDOOR System installation and cabling visual inspection

INDOOR INSTALLATION VISUAL INSPECTION CHECK

OK

NOK

Check Rack allocation according to the station layout

Check Sub-Rack allocation according to the station layout

Check Rack and Sub racks Ground connections

Check TRU or Other Power Supply distributor position and connection

Check Power Supply protection circuit breakers values

Check E1/DS1 - 1 to  8 cabling and labelling on station DDF

Check E1/DS1 - 9 to 16 cabling and labelling on station DDF

Check E3/DS3 cabling and labelling on station DDF

Check IDUs interconnections

(1+1 only)

Check Service Channel cabling and labelling on DDF

(If foreseen by plant doc.)

Check House keeping alarm cabling and labelling on DDF

(If foreseen by plant doc.)

Check NMS supervision Channel interconnection

(If foreseen by plant doc.)

Check EOW Audio Channel interconnection

(If foreseen by plant doc.)

Comment : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative

CUSTOMER representative

Name & signature

Name & signature


Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . . .

OUTOOR System installation and cabling visual inspection

OUTDOOR INSTALLATION VISUAL INSPECTION CHECK

OK

NOK

Check Antenna(s) position according to the plant documentation

Check Antenna(s) Polarisation according to the Plant documentation

Check ODU(s) and pole mounting position according to the plant documentation

Check Antenna(s) EMF warning labelling presence

Check ODU(s) Cable connection waterproofing with rubber tape

Check ODU(s) Grounding

Check IDU/ODU Cable(s) Grounding

Check ODUs RF Coupler Grounding

(1+1 configuration only)

Check Antenna(s) Grounding

(Non integrated Antenna only)

Check Flex twist connection

(Non integrated Antenna only)

Antenna 1

Antenna 2

Polarisation

Diameter

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative,

CUSTOMER representative,

(Name & signature)

(Name & signature)


Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . .

Radio Configuration SUMMARY

Software Key Information

Key Number :

Key Code :

NE Parameters and Frame Configuration

Type :

Market :

Impedance :

Capacity :

Modulation :

Link identifier configuration (optional)

Enabled

Disabled

"Expected" :

"Sent" :

Overhead configuration

User Service Channel Type :

EOW Phone Number

Automatic Restoration Criteria

MUX/DEMUX

Protection :

Revertive

Not Revertive

HST TX

Protection :

Revertive

Not Revertive

RADIO

Protection :

Revertive

Not Revertive

Emission and Reception Frequencies

Channel 1

Channel 0

TX Frequency (KHz)

RX Frequency (KHz)

ALCATEL representative

CUSTOMER representative

Name & signature

Name & signature

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . . .

Radio Power setting and measurement

Tx Power Parameters ATPC Off

Channel 1

Channel 0

Tx nominal power (dbm)

Tx power (dbm)

Tx Power Parameters ATPC ON

Channel 1

Channel 0

Tx nominal power (dbm)

ATPC Range - PTX Min Value (dbm)

ATPC Range - PTX Max Value (dbm)

ATPC Rx Threeshold - Low Power (dbm)

TX and RX Power measurement (with CT)

Channel 1

Channel 0

Expected TX power (dbm)

TX power reading (dbm)

Calculated RX level (dbm)

RX level reading (dbm)

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative

CUSTOMER representative

Name & signature

Name & signature

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .


Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . .

Radio functionnality test

Channel Protection Switching

Protection level

Channel 1 (Forced)

Channel 0 (Lockout)

Radio Protection

OK

NOK

OK

NOK

HST Tx Protection

OK

NOK

OK

NOK

Mux/Demux Protection

OK

NOK

OK

NOK

Loopback Tests

Location

Point

Channel 1

Channel 0

Near End

Tributary

OK

NOK

OK

NOK

Near End

IDU Cable

OK

NOK

OK

NOK

Near End

ODU Cable

OK

NOK

OK

NOK

Near End

RF

OK

NOK

OK

NOK

Far End

Tributary

OK

NOK

OK

NOK

Point to point BER loop Test

Access

Duration

Channel 1

Channel 0

E1/DS1 or E3/DS3

(1 min. each)

OK

NOK

OK

NOK

64 Kbit/s Service Ch.

(10 min.)

OK

NOK

OK

NOK

Ethernet Ch. (optional)

(10 min.)

OK

NOK

OK

NOK

in

E1/DS1 or E3/DS3 "alarm Loss Signal" indication

OK

NOK

OK

NOK

EOW Phone call

Channel 1

Channel 0

Calling the "Radio" Remote Station

OK

NOK

OK

NOK

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative

CUSTOMER representative

Name & signature

Name & signature

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .


Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . . .

NETWORK Element configuration

Local NE IP Address

IP Address :

OSPF AREA Configuration

AREA ID ( 0 - 3 )

IP Address

Stub Flag

IP Mask

NMS IP Point to Point Interface Configuration

Interface

Status

Remote IP Address

OSPF

NMS V11

Enabled

Disabled

NMS G703

Enabled

Disabled

NMS Radio Side

Enabled

Disabled

Ethernet (OS) configuration

Enabled

Disabled

IP Address

IP Routing

IP Mask

IP static routing configuration

Host

Network

IP Address

IP Mask

Default Gateway IP Address

Point to Point Interface Index

RF

V11

G703

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative

CUSTOMER representative

Name & signature

Name & signature

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . .


Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . .

NETWORK Element Integration test

NMS radio side NE Acquisition

Expected Functionality

Channel 1

Channel 0

Supervising with CT the Radio Side remote Station

OK

NOK

OK

NOK

Line Side functionality (Only if foreseen by Plant Doc.)

Supervising with CT a Line Side remote Station

OK

NOK

Calling with EOW a Line side Remote Station

OK

NOK

House keeping Input alarms acquisition (Only if foreseen by Plant Doc.)

Alarm / User label

Acquisition on CT

Alarm / User label

Acquisition on CT

CPI 1 / . . . . . . . . . . . .

OK

NOK

CPI 4 /. . . . . . . . . . . . .

OK

NOK

CPI 2 /. . . . . . . . . . . . .

OK

NOK

CPI 5 / . . . . . . . . . . . .

OK

NOK

CPI 3 / . . . . . . . . . . . .

OK

NOK

CPI 6 /. . . . . . . . . . . . .

OK

NOK

House keeping Output alarms Detection (Only if foreseen by Plant Doc.)

Alarm / User label

Detection

Alarm

Detection

CPO 1 /. . . . . . . . . . . . .

OK

NOK

Fail IDU

OK

NOK

CPO 2 /. . . . . . . . . . . . .

OK

NOK

Fail ODU CH#1

OK

NOK

CPO 3 /. . . . . . . . . . . . .

OK

NOK

Fail ODU CH#0

OK

NOK

CPO 4 /. . . . . . . . . . . . .

OK

NOK

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative

CUSTOMER representative

Name & signature

Name & signature


Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . .

HOP stability test

2 hours BER Loop test on one tributary without error

OK

NOK

Result printing:

SHAPE \* MERGEFORMAT

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative

CUSTOMER representative

Name & signature

Name & signature


BLANK

SITE ACCEPTANCE TEST PROTOCOL


STATION HOP

STATION NAME :.......... ..... ...... .......

DIRECTION :.......... ..... ...... ... ........

HOP : .......... ..... ...... .............

CONFIGURATION : .. AWY

CUSTOMER : .......... ..... ...... .......

CONTRACT NUMBER : .......... ..... ...... ..

Accepted Without pending point

With pending point Major Minor


Refused

PENDING POINT(s):

ALCATEL representative

Company : . . . . . . . . . . . . .

Name : . . . . . . . . . . . . . .

Signature :

Date : . . . / . . . / . . . .

CUSTOMER representative

Company : . . . . . . . . . . . . .

Name : . . . . . . . . . . . . . .

Signature :

Date : . . . . / . . . / . . . .


END OF DOCUMENT


Document Info


Accesari: 2956
Apreciat: hand-up

Comenteaza documentul:

Nu esti inregistrat
Trebuie sa fii utilizator inregistrat pentru a putea comenta


Creaza cont nou

A fost util?

Daca documentul a fost util si crezi ca merita
sa adaugi un link catre el la tine in site


in pagina web a site-ului tau.




eCoduri.com - coduri postale, contabile, CAEN sau bancare

Politica de confidentialitate | Termenii si conditii de utilizare




Copyright © Contact (SCRIGROUP Int. 2024 )
