Chapter ODU PROVISIONING, CHARACTERISTICS AND DESCRIPTION, for detailed information regarding ODU Part Numbers and related frequency shifters and frequency bands.

To easily find such information, or any other information you may need (and that is not included in this handbook), please refer to the document Documentation Quick Guide accessible from the CD-ROM MAIN MENU.

STATION

. . . . . . . . . . . . . . . . . . .

Direction

. . . . . . . . . . . . . . . .

Configuration

. . . . . . . . . . . . . . . . . . . . . .

Date

. . . . / . . . / . . . .

BLANK

TEST RESULT

TOC \o "1-3" \t "h:1;1;h:2;2;h:3;3;H:4;4;H:5;5" Threshold tables PAGEREF _Toc153767684 \h 2 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380034000000

System installation and cabling visual inspection PAGEREF _Toc153767685 \h 6 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380035000000

INDOOR System installation and cabling visual inspection PAGEREF _Toc153767686 \h 6 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380036000000

OUTOOR System installation and cabling visual inspection PAGEREF _Toc153767687 \h 7 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380037000000

Radio Configuration SUMMARY PAGEREF _Toc153767688 \h 8 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380038000000

Radio Power setting and measurement PAGEREF _Toc153767689 \h 9 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600380039000000

Radio functionnality test PAGEREF _Toc153767690 \h 10 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600390030000000

NETWORK Element configuration PAGEREF _Toc153767691 \h 11 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600390031000000

NETWORK Element Integration test PAGEREF _Toc153767692 \h 12 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600390032000000

HOP stability test PAGEREF _Toc153767693 \h 13 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600390033000000

SITE ACCEPTANCE TEST PROTOCOL PAGEREF _Toc153767694 \h 15 08D0C9EA79F9BACE118C8200AA004BA90B02000000080000000E0000005F0054006F0063003100350033003700360037003600390034000000

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . .

System installation and cabling visual inspection

INDOOR System installation and cabling visual inspection

INDOOR INSTALLATION VISUAL INSPECTION CHECK		OK	NOK
Check Rack allocation according to the station layout
Check Sub-Rack allocation according to the station layout
Check Rack and Sub racks Ground connections
Check TRU or Other Power Supply distributor position and connection
Check Power Supply protection circuit breakers values
Check E1 "1 to 8" cabling and labelling on station DDF
Check E1 "9 to 16" cabling and labelling on station DDF
Check E3 cabling and labelling on station DDF
Check IDUs interconnections	(1+1 only)
Check Service Channel cabling and labelling on DDF	(If foreseen by plant doc.)
Check House keeping alarm cabling and labelling on DDF	(If foreseen by plant doc.)
Check NMS supervision Channel interconnection	(If foreseen by plant doc.)
Check EOW Audio Channel interconnection	(If foreseen by plant doc.)

Comment : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative

CUSTOMER representative

Name & signature

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . . .

OUTOOR System installation and cabling visual inspection

OUTDOOR INSTALLATION VISUAL INSPECTION CHECK		OK	NOK
Check Antenna(s) position according to the plant documentation
Check Antenna(s) Polarisation according to the Plant documentation
Check ODU(s) and pole mounting position according to the plant documentation
Check Antenna(s) EMF warning labelling presence
Check ODU(s) Cable connection waterproofing with rubber tape
Check ODU(s) Grounding
Check IDU/ODU Cable(s) Grounding
Check ODUs RF Coupler Grounding	(1+1 configuration only)
Check Antenna(s) Grounding	(Non integrated Antenna only)
Check Flex twist connection	(Non integrated Antenna only)

	Antenna 1	Antenna 2
Polarisation
Diameter

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative,

CUSTOMER representative,

(Name & signature)

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . .

Radio Configuration SUMMARY

Software Key Information

Key Number :

Key Code :

NE Parameters and Frame Configuration

Type :

Market :

ETSI

Impedance :

Capacity :

Modulation :

Link identifier configuration (optional)

Enabled

Disabled

"Expected" :

"Sent" :

Overhead configuration

User Service Channel Type :

EOW Phone Number

Automatic Restoration Criteria

MUX/DEMUX

Protection :

Revertive

Not Revertive

HST TX

Protection :

Revertive

Not Revertive

RADIO

Protection :

Revertive

Not Revertive

Emission and Reception Frequencies

Channel 1

Channel 0

TX Frequency (KHz)

RX Frequency (KHz)

ALCATEL representative

CUSTOMER representative

Name & signature

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . . .

Radio Power setting and measurement

Tx Power Parameters ATPC Off
	Channel 1	Channel 0
Tx nominal power (dbm)
Tx power (dbm)

Tx Power Parameters ATPC ON
	Channel 1	Channel 0
Tx nominal power (dbm)

ATPC Range - PTX Min Value (dbm)
ATPC Range - PTX Max Value (dbm)

ATPC Rx Threeshold - Low Power (dbm)

TX and RX Power measurement (with CT)
	Channel 1	Channel 0
Expected TX power (dbm)
TX power reading (dbm)

Calculated RX level (dbm)
RX level reading (dbm)

ALCATEL representative

CUSTOMER representative

Name & signature

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . .

Radio functionnality test

Channel Protection Switching
Protection level			Channel 1 (Forced)		Channel 0 (Lockout)
Radio Protection			OK	NOK	OK	NOK
HST Tx Protection			OK	NOK	OK	NOK
Mux/Demux Protection			OK	NOK	OK	NOK

Loopback Tests
Location	Point		Channel 1		Channel 0
Near End	Tributary		OK	NOK	OK	NOK
Near End	IDU Cable		OK	NOK	OK	NOK
Near End	ODU Cable		OK	NOK	OK	NOK
Near End	RF		OK	NOK	OK	NOK

Far End	Tributary		OK	NOK	OK	NOK

Point to point BER loop Test
Access		Duration	Channel 1		Channel 0
E1 or E3		(1 min. each)	OK	NOK	OK	NOK
64 Kbit/s Service Ch.		(10 min.)	OK	NOK	OK	NOK
Ethernet Ch. (optional)		(10 min.)	OK	NOK	OK	NOK
			in
E1 or E3 "alarm Loss Signal" indication			OK	NOK	OK	NOK

EOW Phone call
			Channel 1		Channel 0
Calling the "Radio" Remote Station			OK	NOK	OK	NOK

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative

CUSTOMER representative

Name & signature

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . . .

NETWORK Element configuration

Local NE IP Address

IP Address :

OSPF AREA Configuration

AREA ID ( 0 - 3 )

IP Address

Stub Flag

IP Mask

NMS IP Point to Point Interface Configuration

Interface

Status

Remote IP Address

OSPF

NMS V11

Enabled

Disabled

NMS G703

Enabled

Disabled

NMS Radio Side

Enabled

Disabled

Ethernet (OS) configuration

Enabled

Disabled

IP Address

IP Routing

IP Mask

IP static routing configuration

Host

Network

IP Address

IP Mask

Default Gateway IP Address

Point to Point Interface Index

V11

G703

Comment: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ALCATEL representative

CUSTOMER representative

Name & signature

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . .

NETWORK Element Integration test

NMS radio side NE Acquisition

Expected Functionality

Channel 1

Channel 0

Supervising with CT the Radio Side remote Station

NOK

Line Side functionality (Only if foreseen by Plant Doc.)

Supervising with CT a Line Side remote Station

NOK

Calling with EOW a Line side Remote Station

NOK

House keeping Input alarms acquisition (Only if foreseen by Plant Doc.)

Alarm / User label

Acquisition on CT

Alarm / User label

Acquisition on CT

CPI 1 / . . . . . . . . . . . .

NOK

CPI 4 /. . . . . . . . . . . . .

NOK

CPI 2 /. . . . . . . . . . . . .

NOK

CPI 5 / . . . . . . . . . . . .

NOK

CPI 3 / . . . . . . . . . . . .

NOK

CPI 6 /. . . . . . . . . . . . .

NOK

House keeping Output alarms Detection (Only if foreseen by Plant Doc.)

Alarm / User label

Detection

Alarm

Detection

CPO 1 /. . . . . . . . . . . . .

NOK

Fail IDU

NOK

CPO 2 /. . . . . . . . . . . . .

NOK

Fail ODU CH#1

NOK

CPO 3 /. . . . . . . . . . . . .

NOK

Fail ODU CH#0

NOK

CPO 4 /. . . . . . . . . . . . .

NOK

ALCATEL representative

CUSTOMER representative

Name & signature

Station : . . . . . . . . . . . . . . . . . . . . Direction : . . . . . . . . . . . . . . .

Configuration : . . . . . . . . . . . . . . . . . . . . . Date : . . . . / . . . / . . .

HOP stability test

2 hours BER Loop test on one tributary without error

NOK

Result printing:

SHAPE \* MERGEFORMAT

ALCATEL representative

CUSTOMER representative

Name & signature

BLANK

SITE ACCEPTANCE TEST PROTOCOL

STATION HOP

STATION NAME :.......... ..... ...... .......

DIRECTION :.......... ..... ...... ... ........

HOP : .......... ..... ...... .............

CONFIGURATION : .. AWY

CUSTOMER : .......... ..... ...... .......

CONTRACT NUMBER : .......... ..... ...... ..

Accepted Without pending point

With pending point Major Minor

Refused

PENDING POINT(s):

ALCATEL representative

Company : . . . . . . . . . . . . .

Name : . . . . . . . . . . . . . .

Signature :

Date : . . . / . . . / . . . .

CUSTOMER representative

Company : . . . . . . . . . . . . .

Name : . . . . . . . . . . . . . .

Signature :

Date : . . . . / . . . / . . . .

END OF DOCUMENT
