CISCO SYSTEMS
CCIE Preparation
Multiprotocol Skills Laboratory
NAME :
COMPANY:
DATE:
NETWORK DIAGRAM
Lab 1. Connect Terminal Server (1 hour)
1. &n 111e48b bsp; Setup routers as shown in the diagram above:
2. &n 111e48b bsp; Configure a ip host list for a reverse telnet session into each router.
Lab 2. IP (6 hours)
· &n 111e48b bsp; Configure the network using network 130.10.x.x
· &n 111e48b bsp; Use an 8 bit subnet mask unless otherwise specified
At the end of each exercise, verify connectivity between all ports:
· &n 111e48b bsp; All ip routes appearing in all routers
· &n 111e48b bsp; Ping from any interface to any other interface
Lab 2a
1. &n 111e48b bsp; Connect R6, R1, and R5 over Frame Relay. Use single subnet over the frame cloud.
2. &n 111e48b bsp; Configure OSPF with the cloud in area 0. Configure R2, R3 and R1-R2 serial to be in area 1.
3. &n 111e48b bsp; Configure two loopbacks on R6 using subnets that will contain at most 14 host ip addresses. Configure two loopbacks on R5 using subnets that will contain at most 62 hosts. Summarize the two loopback interfaces on R6 and R5 such that R1 only sees one route from each.
Lab 2b
1. &n 111e48b bsp; Remove OSPF configurations from R2, R3 and the serial connection between R1 and R2. Configure EIGRP on R2, R3 and on the serial connection between R1 and R2. Redistribute OSPF and EIGRP on R1.
2. &n 111e48b bsp; Repeat step 1 using IGRP instead of EIGRP.
Lab 2c
1. &n 111e48b bsp; Filter such that R3 can ping the loopbacks on R5 but not the ethernet. The route for the ethernet should still be visible.
2. &n 111e48b bsp; Filter on R2 such that R6, R5, and R1 only see the routes from the token-ring interface on R3.
3. &n 111e48b bsp; Remove the filters from R2.
Lab III. Appletalk (1 hour)
At the end of each exercise, verify connectivity between all ports:
· &n 111e48b bsp; All Apple routes/zones appearing in all routers
· &n 111e48b bsp; Apple ping from any interface to any other interface
Lab 3a
1. &n 111e48b bsp; Configure all ports (except loopbacks) for appletalk. Define a zone on each interface. Define an interface on R3 as Appletalk phase I.
2. &n 111e48b bsp; Configure EIGRP for R1, R2, and R3.
3. &n 111e48b bsp; Configure RTMP/ZIP for the NBMA network.
Lab 3b
1. &n 111e48b bsp; Filter on R2 such that R3 only sees routes and zones from R6.
Lab 3c
1. &n 111e48b bsp; Remove Appletalk from the serial network between R1 and R2. All zones and routes should still be seen by all routers running Appletalk.
Lab IV. DECnet (30 minutes)
At the end of each exercise, verify connectivity between all ports
· &n 111e48b bsp; Appropriate DEC areas/nodes appearing in all routes
· &n 111e48b bsp; DEC ping from any router to any other router
Lab 4a
1. &n 111e48b bsp; Enable DECnet routing on all routers. Configure R2 and R3 in a separate DECnet area from the rest of the routers.
Lab V. IPX (1 hour)
At the end of each exercise, verify connectivity between all ports.
· &n 111e48b bsp; Appropriate IPX routes/SAP's appearing in all routers
· &n 111e48b bsp; IPX ping from any interface to any other interface
Lab 5a
1. &n 111e48b bsp; Configure all ports (including loopbacks) for IPX.
2. &n 111e48b bsp; ConfigureRIP/SAP on R2, R3, and the serial network between R1 and R2.
3. &n 111e48b bsp; Configure only EIGRP on R6, R5, and R1's NBMA network interface.
4. &n 111e48b bsp; Redistribute on R1.
Lab 5b
1. &n 111e48b bsp; Configure two static SAPs on R3. Filter on R2 such that R6, R5, and R1 see only one of theSAPs.
2. &n 111e48b bsp; Disable IPX across the NBMA network. All routes should still be seen by all routers running IPX.
3. &n 111e48b bsp; Change the frequency of RIP updates across the token-ring connection between R2 and R3 to once every 2 minutes.
Lab VI. Dial-on-demand routing (2 hours)
At the end of each exercise, verify connectivity between all ports:
· &n 111e48b bsp; Ping all interfaces using applicable protocols
Lab 6a
1. &n 111e48b bsp; Configure an ISDN connection between R1 and R2.
2. &n 111e48b bsp; Disconnect the serial link between R1 and R2.
3. &n 111e48b bsp; Configure dial-on-demand routing for IP and IPX between R1 and R2. No broadcast packets should initiate the dialing.
4. &n 111e48b bsp; Reconnect the serial link between R1 and R2 and shut down the ISDN interfaces.
Lab VII. DLSW (1 hour)
Lab 7a
1. &n 111e48b bsp; Configure DLSW between Ring1 and Ring 3.
2. &n 111e48b bsp; Add R1's ethernet into the DLSW network. Make sure there is connectivity between all lan interfaces.
Lab 7b
1. &n 111e48b bsp; Configure a filter that blocks Netbios packets with destination name "ARIZONAWILDCATS" from leaving Ring 3.
2. &n 111e48b bsp; Set up a filter that would permit only SNA traffic between the token-rings.
Lab VIII. BGP (1 hour)
1. &n 111e48b bsp; Remove the routing protocol from the serial link between R1 and R2. Create a BGP autonomous network between these routers. For the AS containing R2 and R3, configure the network using network 140.20.0.0. Redistribute and aggregate all routes.
Lab IX. HSRP (1 hour)
1. &n 111e48b bsp; Connect 3 routers to an ethernet as shown below.
2. &n 111e48b bsp; Define IP addresses on all interfaces. Configure a loopback interface on R2 and give it an IP address.
3. &n 111e48b bsp; Setup any type of connections and any type of IP routing between R1, R2 and R3.
4. &n 111e48b bsp; Disable IP routing on R5 and configure it as an IP host..
5. &n 111e48b bsp; Configure HSRP between R1 and R3.
6. &n 111e48b bsp; You should be able to disconnect the ethernet on either R1 or R3 and still be able to ping the loopback on R2 from R5.
|
