New Advanced Hybrid PBX KX-TA308/TA616

Edition

Date of issue 151b12b

Modification

Note

1^st

13 Jan., 2000

1^st Edition

2^nd

14 Mar., 2000

Add detailed the following items in Ver. Y551U

18- When you set [920]Pay-Tone assignment

25- Hold re-call ringing program is modified.

(A)

3^rd

11 May, 2000

Hardware change

(B)

4^th

11 July, 2000

Software Version up to Y581F

5^th

15 Feb., 2001

1. Suffix G information (R&TTE)

2. Hardware change R159/R160 form 100K to 220K

ROM

Version

Check

Sum

Modification

Mass-Production

Y501J

Suffix-A

77B0

First Version

[Installation Manual]   PSQX1315XA

[User Manual]  PSQX1317XA

From

Dec. 1998

Y501J

Suffix-B

77B0

[Software]  No change

[Hardware]

Add C16 (0.0047uf) into power unit.

Change the power unit number from PCSP1074ZB to PCSP1074ZC

[Installation Manual]   No change

[User Manual]  No change

From

May. 1999

Y551H

Suffix-C

781E

[Software]

DISA OGM disconnect program is modified.

LCD message (Czech) is modified.

CPC detection time [420] default is changed N=32(350ms) to N=00 (disable)

Timed reminder program is modified. (Some time it is ringing in out of setting time.)

[Hardware]  No change

[Installation Manual]   No change

[User Manual]  No change

From

June. 1999

Y551U

Suffix-D

E6B0

[Software]

Selectable extension number 3 digit or 2 digit. (Y505J and Y551H supported 3 digit only)

Add Flexible Extension Numbering

Changed Program [009] Extension Number Assignment.

Add the Program [012] Second Feature Numbering Plan.

(Old) Fix 3 digits (100-199)

(New) You can select following 3 extension numbering plans.

Plan-1: 3 digits (100-199)-Default

Plan-2: 3 digits (100-499)

Plan-3: 2 digits (10-49)

ARS mode is added.

Add the Program [350]-[364]

Modify Alternate Call

(Old) 'Voice -> Ring'

(New) Both 'Voice -> Ring' and 'Ring -> Voice'

Add Speed Dial Name/Caller-ID Number -> Name Translation

Add the program [011] Speed Dialing Name Setting.

Increase Caller-ID Log Area

(Old) 5 calls per Extension (only Manager/Operator is 20 calls).

(New) 20 calls per Extension (All Extension are 20 calls).

Increase the Caller-ID area code from 1 to 5.

Changed the program [901].

Increase Redial digits max. 32 -> 64.

Change Account Code - Verify Toll Mode

(Old) Extension user has to external account code every time.

(New) Extension user may enter account code only he want to override Toll-Restriction.

One-Touch dialing number digit 16 to 24.

It is possible to do hooking function immediate after outside dialing from SLT.

From

Nov. 1999

Add OGM Mode-6 by Prog[502].

When all UCD group members are busy and UCD Timer expired system intercept this call to DISA and caller hear another OGM.

Change the program [502][521] 1mit-32mit to 1sec-32sec.

Increase Emergency call digits max 4->11.

Changed the program [309].

Toll restriction digit, code are changed.

[302]-[306] 10 digit to 11 digit

[306] Code 20 entry to 80 entry.

[309] 5 digit to 11 digit.

Pick-up feature is modified.(it is possible to answer a call just pick up a handset) (it is selectable on [127])

Dialing feature on DSS console is modified.(it is possible to make a call just pressing a DSS key) (it is selectable on [126])

LCD, SMDR Slovakia message is added.

Change the program [605][806].

Czech standard mode is added.

Change the program [991]

When you set [920]Pay-Tone assignment Enable but system does not receive Pay-Tone, then system print out the call to SMDR. (Now not print out)

(A) The system print out outgoing call information when a calling time is exceeded against for [204] Call Duration Count Start Time, it performs even if Pay-Tone is not sent from PTT.

DISA security code [512] default is changed.

("0000" to "Not Stored")

Dial tone is changed when entering account code.

Non page feed (SMDR) when Call-Log output mode is enable.

Printing out Caller-ID information feature is added. (it is selectable on [907])

Add waiting function for DISA incoming call when OGM 2 is busy.

(Current: Wait / Previous: Disconnect)

24. Incoming mode (Previous: Connect) for DND extension via DISA is modified. (It is selectable on [506] / Disconnect, Call waiting, DISA-2)

25. Hold re-call ringing program is modified.

(Hold re-call timer program has an inappropriate sequence)

(A) Old:

When you hold first call, the first re-call timer starts for the first call.

2- The second call arrive at your extension

3- You hold the second call, the second re-call timer starts for the second call. But the first re-call timer for the first call re-starts again.

4- The third call arrives at your extension.

5- You hold the third call, the third re-call timer starts for this call.

But the first and second re-call timer re-start again.

Now:

1- When you hold first call, the first re-call timer starts for the first call.

2- The second call arrive at your extension

3- You hold the second call, the second re-call timer starts for the second call.

The first re-call timer for the first call not re-starts.

Add two bell-on detection times (312/580ms) into [964].

(72/144/312/580ms)

Add a feature (program) after detecting over load.

Add an intercept program when receive DISA illegal dialing.

[990] Taiwan mode is added

Modify paging bug.

Modify pickup dialing function.

Modify FWD function.(A FAX call is not forwarded)

Modify Caller-ID LCD message. (Argentina)

[Hardware] No change

[Installation Manual]   Change to PSQX1315WA-H

[User Manual] Change to PSQX1217WA-H

[Leaflet] Add to PSQW1446ZA

Y551U

Suffix-E

(B)

E6B0

[Software] No change

[Hardware]

Change following parts for countermeasure of KX-TA308CE/KX-TA616CE self-reset problem which reported on Russian model only.

R123,R124,R125: from PQLQR1RM601T-Y to ERJ3GEYJ390V

From

May, 2000

Y581F

Suffix-F

10B9

[Software]

1. Add A-PITS integration for New Voice Mail KX-TVP50.

-- Additional feature --

2way recording/2way transfer/Voice mail transfer/Live Call Screen

-- Add the following Program --

[130] Voice Mail 1 APT Port for KX-TVP50

[131] Voice Mail 2 APT Port for KX-TVP50

[620] Live Call Screening Recording Mode Assignment

[963] Call Forwarding Selection

In detail, please see the attached O/I for KX-TVP50 (PSQX2079ZA).

2. [Request from Poland]

Add the program '[530] DISA Security code digits selection'.

We add the selection for security.

In detail, please see the attached leaflet (PSQW1527ZA).

3. [Request from Spain/Hong Kong]

Add the Manager Extension (Jack-01) can program as following when he enter his extension password instead of system password.

[001] System Speed Dialing

[011] System speed Dialing Name setting

[512] DISA Security Codes

[530] DISA Security Code digits selection

In detail, please see the attached leaflet (PSQW1527ZA).

4. [Request from Greece]

Add the Remote Station Lock Operation from Manager/Operator without DSS console. We add the numbering.

Locked : 7** [Ext. No.][Ext. No.] #

Unlocked : 7** [Ext. No.] #

For example, when operator want to lock the room number 105,

Then he/she lift the handset and dial 7**105105# .

When he/she want to unlock, dial 7**105# .

(If you set PF key to 7**, I think it is convenient, because operation is more simple. ex. [PF]105105# [PF]105# )

** We will describe the manual at the next chance.**

5. [Request from Greece]

Add the SMDR print for Hotel mode.

Add the program '[929] SMDR Hotel Mode'.

Enable --- Normal SMDR is not print-out.

Disable -- Normal SMDR is print-out. (Default)

You must set [802] to 'Outgoing-On' in Hotel.

** We will describe the manual at the next chance.**

6. Increase [311]Automatic Pause Insertion Code.

Y551U: 7 digits

Y581F: 11 digits

[Hardware] No change

From

July, 2000

Y581F

Suffix-G

10B9

Fulfill the R&TTE (Radio and telecommunications terminal equipment directive)/EU Directive

Change the carton box, and add a leaflet (PSW1576ZA)

[Hardware] No change

[Software] No change

From

Nov., 2000

Y581F

Suffix-H

10B9

[Hardware]

R159 and R160 from 100K to 220K

Reason

When dial to CO form T7330/20 by SP-phone mode and paralleled connection mode, DTMF signal is sent to PBX mail unit (TA308/TA616) through data line (H/L Line) and through T/R line at the same time. Because DTMF feed back signal from the speaker is leaked to the microphone (to T/R line).

Symptom

Miss-dialing (Double dialing)

This symptom happens only on Ext. 101,108 (Main Card)

[Software] No change

From

Feb., 2001
